LED ORIENT TECHNOLOGY CO., LTD
| INDOOR P4 SMD 3IN1 TECHNICAL PARAMETERS | ||
| Module | Item | Parameter |
| Model Number | ZX-P4-INDOOR-80-40 | |
| Module size | 320mm*160mm | |
| Module thickness | 15mm, 27mm | |
| Pixel pitch | 4mm | |
| Pixels Density | 62500dot/m2 | |
| Pixel configuration | 1R1G1B | |
| Package mode | SMD2121 | |
| Pixel resolution | 80dots(W)*40dots(H) | |
| Max Power | 25W | |
| Weight | 0.208kg/0.242kg | |
| Drive type | Constant drive | |
| Scan mode | 1/20scan | |
| Port type | HUB75 | |
| Brightness of white balance | 900cd/m2 | |
| Main technical parameter | Driving device | Constant drive IC |
| Refresh frequency | >1920HZ | |
| Grey scale/colors | 4096gray level/16.7M colors | |
| MTBF | >9000hours | |
| Power switch | Automatic switch | |
| Working voltage | DC 5V ±10% | |
