LED ORIENT TECHNOLOGY CO., LTD
INDOOR P2 SMD 3IN1 TECHNICAL PARAMETERS | ||
Module | Item | Parameter |
Model Number | P2-20S | |
Module size | 320mm*160mm | |
Module thickness | 13mm | |
Pixel pitch | 2mm | |
Pixels Density | 25000dot/m2 | |
Pixel configuration | 1R1G1B | |
Package mode | SMD 3IN1 -1515 | |
Pixel resolution | 160dots(W)*80dots(H) | |
Max Power | 23W | |
Weight | 0.452KG | |
Drive type | Constant drive | |
Scan mode | 1/20can | |
Port type | HUB320/HUB75 | |
Brightness of white balance | ≥800cd/m2 | |
Best viewing distance | 2M~10M | |
Best viewing angle | 140°(W) 120°(H) | |
Temperature | (Storage) 35℃~+85℃, (Working) -20℃~+50℃ | |
Relative humidity | 10%-95% | |
Working voltage | DC 5V | |
Average Power consumption | <280W/㎡ | |
Max.Power consumption | <439W/㎡ | |
Current | <15mA(single LED) | |
Main technical parameter | Driving device | Constant drive IC |
Refresh frequency | >1920HZ | |
Grey scale/colors | 65536gray level/16.7M colors | |
MTBF | >9000hours | |
Power switch | Automatic switch | |
Working voltage | DC 5V ±10% |
