LED ORIENT TECHNOLOGY CO., LTD
INDOOR P3 SMD 3IN1 TECHNICAL PARAMETERS | ||
Module | Item | Parameter |
Model Number | P3-32S | |
Module size | 192mm*192mm | |
Module thickness | 15mm, 27mm | |
Pixel pitch | 3mm | |
Pixels Density | 111111dot/m2 | |
Pixel configuration | 1R1G1B | |
Package mode | SMD2121 | |
Pixel resolution | 64dots(W)*64dots(H) | |
Max Power | 23W | |
Weight | 0.31kg | |
Drive type | Constant drive | |
Scan mode | 1/32scan | |
Port type | HUB75E | |
Brightness of white balance | 1200cd/m2 | |
Best viewing distance | 3M~20M | |
Best viewing angle | 160°(W) 120°(H) | |
Temperature | (Storage) 35℃~+85℃, (Working) -20℃~+50℃ | |
Relative humidity | 10%-95% | |
Working voltage | DC 5V | |
Average Power consumption | <270W/㎡ | |
Max.Power consumption | <780W/㎡ | |
Current | <18mA(single LED) | |
Main technical parameter | Driving device | Constant drive IC |
Refresh frequency | >3840HZ | |
Grey scale/colors | 16384gray level/16.7M colors | |
MTBF | >9000hours | |
Power switch | Automatic switch |
